Default alum heads vs cast iron heads

helping a guy on a 96 Impala SS. Stock has the cast iron heads. it blew the headgasket overheated and cracked the head. i know its junk. So now im helping look for new heads. If i found one that matched he might want to go that way, but if not then i could go alum or cast right.

Are there any differences in lt1 heads as far and flow, combustion chamber size and design. Which should i be looking for Alum -Cast, and not have to retune.
__________________
77 camaro 454 (project)
79 GMC c10 454 (sold)
86 Camaro 350 (drag)
89 S10 305 (peg legger)
93 Firebird LT1 (Daily Driver)
(Pasesetter LT, ORY, Flowmaster,K&N FIPK, CSR Electric Water pump,Air Foil, 160 Thermostat, MSD wires, NGK TR6, 150 Wet Shot NOS, PCMforless tune.)

Last edited by 93formulat-top; 02-20-2009 at 10:40 PM.
93formulat-top is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Sponsored Links
Advertisement

Old 02-20-2009, 10:29 PM   #2
Regular Member

91slowmaro's Avatar

Join Date: Dec 2008
Location: Montezuma IN
Posts: 22
91slowmaro user's tech expertise is unknown at this point
Default

Bit confused hear did you mean an Impala ss dont think the monty has a lt1
__________________
95 lt1 4l60e headers ory catback k&n cold air free mods pa racing k- member a arms eibach springs I think you can take me its just a 305
91slowmaro is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 02-20-2009, 10:35 PM   #3
Regular Member

93formulat-top's Avatar

Join Date: Sep 2008
Location: Dodge City KS
Posts: 79
My Facebook
93formulat-top user's tech expertise is unknown at this point
Default

yea sorry i got confused talking on the phone about another car while typing
__________________
77 camaro 454 (project)
79 GMC c10 454 (sold)
86 Camaro 350 (drag)
89 S10 305 (peg legger)
93 Firebird LT1 (Daily Driver)
(Pasesetter LT, ORY, Flowmaster,K&N FIPK, CSR Electric Water pump,Air Foil, 160 Thermostat, MSD wires, NGK TR6, 150 Wet Shot NOS, PCMforless tune.)
93formulat-top is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 02-20-2009, 11:07 PM   #4
CKJ
Guest

Posts: n/a
Default

The cast heads flow better untouched, but the aluminum heads weigh less and of course disperse heat better. I have a set of cast 350 LT1 heads off of a 94 Caprice for sale for 50 bucks + shipping.

Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 02-21-2009, 09:20 PM   #5
Regular Member

Join Date: Dec 2007
Location: The Fiesta City
Posts: 2,139
KW Baraka Apprentice Level Tech III
Default

Quote:
Originally Posted by CKJ View Post
The cast heads flow better untouched, but the aluminum heads weigh less and of course disperse heat better........
Not to mention that the aluminum heads have smaller combustion chambers and thus, a higher compression ratio.

Still......if I had the choice of iron heads for $50 or aluminum heads for $200......I just may opt for the irons, since the aluminums aren't $150 better in stock form.

KW
KW Baraka is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 02-21-2009, 09:36 PM   #6
Administrator

03slowZ06's Avatar

Join Date: Jul 2006
Location: Jacksonville
Posts: 7,520
03slowZ06 Apprentice Level Tech III
Send a message via Yahoo to 03slowZ06
Default

KW Do you know how much meat can be cleaned off the cast heads?
__________________
03 Z06, LTs, A&A P1SC running 6psi, 550/471
Quote:
Originally Posted by 94FormulaBird View Post
drivers side is a dream....passenger side on the other hand...i lost 2 screwdrivevers and a socket when i chucked them in the woods

u can do it



I am permanently banned from all petting zoo's for getting to friendly
03slowZ06 is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 02-21-2009, 09:41 PM   #7
Regular Member

Join Date: Dec 2007
Location: The Fiesta City
Posts: 2,139
KW Baraka Apprentice Level Tech III
Default

Quote:
Originally Posted by 03slowZ06 View Post
KW Do you know how much meat can be cleaned off the cast heads?
No.......

To be honest, the B-body crowd don't do a lot of porting or decking of the iron heads......too much trouble!

I'd say that more than 99% of us running ported heads are using the aluminums or aftermarkets. Almost no one is running ported LT1 irons.

KW
KW Baraka is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 02-21-2009, 09:45 PM   #8
Administrator

03slowZ06's Avatar

Join Date: Jul 2006
Location: Jacksonville
Posts: 7,520
03slowZ06 Apprentice Level Tech III
Send a message via Yahoo to 03slowZ06
Default

Gotcha. Thats good to know.
__________________
03 Z06, LTs, A&A P1SC running 6psi, 550/471
Quote:
Originally Posted by 94FormulaBird View Post
drivers side is a dream....passenger side on the other hand...i lost 2 screwdrivevers and a socket when i chucked them in the woods

u can do it



I am permanently banned from all petting zoo's for getting to friendly
03slowZ06 is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 02-22-2009, 12:57 AM   #9
Regular Member

burnzilla's Avatar

Join Date: Apr 2006
Posts: 510
burnzilla Apprentice Level Tech III
Default

What do you even use to port cast iron?
Hi-level torches? Haha
__________________

1995 Z28 A4
burnzilla is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 02-22-2009, 05:28 AM   #10
CKJ
Guest

Posts: n/a
Default

You just mostly use a porting bit that doesn't have as big a opening between the cutters. We've got some at the shop that could probably be used to port a set of cast iron heads but we use them for general metal work.

Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 02-22-2009, 10:37 AM   #11
Regular Member

93formulat-top's Avatar

Join Date: Sep 2008
Location: Dodge City KS
Posts: 79
My Facebook
93formulat-top user's tech expertise is unknown at this point
Default

Hey CKJ Im really interested in the heads.
Do u have any pics, how many miles, have u looked them over for cracks, are they assembled so i can do a valve job mill and go?
He also wants to know if they turn out to be cracked can he get his money back?
How much would shiping be to 67801.
Hes tring to do this on a budget.

Thanks,
Mark
__________________
77 camaro 454 (project)
79 GMC c10 454 (sold)
86 Camaro 350 (drag)
89 S10 305 (peg legger)
93 Firebird LT1 (Daily Driver)
(Pasesetter LT, ORY, Flowmaster,K&N FIPK, CSR Electric Water pump,Air Foil, 160 Thermostat, MSD wires, NGK TR6, 150 Wet Shot NOS, PCMforless tune.)
