Default Trying to remove engine- Flexplate won't spin

So I just got a '94 Trans Am with a blown engine- so I have to pull it and rebuild it. The only places the engine is connected at are the engine mounts, the two lower bellhousing bolts, and the flexplate. I can't seem to rotate the flexplate at all to get to the other bolts on it. It's not that I'm weak- at least I don't think I'm weak (6'2" 195lb. 19yrs old that works out a lot- please don't email me- not looking at dating any of you)- so I don't see a problem why the flexplate won't spin at all. Some help please!
bcortell is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Sponsored Links
Advertisement

Old 07-13-2008, 03:42 PM   #2
Regular Member

Join Date: Jul 2008
Location: Cleveland, OH
Posts: 12
bcortell user's tech expertise is unknown at this point
Default Trying to remove engine- Flexplate won't spin

So I just got a '94 Trans Am with a blown engine- so I have to pull it and rebuild it. The only places the engine is connected at are the engine mounts, the two lower bellhousing bolts, and the flexplate. I can't seem to rotate the flexplate at all to get to the other bolts on it. It's not that I'm weak- at least I don't think I'm weak (6'2" 195lb. 19yrs old that works out a lot- please don't email me- not looking at dating any of you)- so I don't see a problem why the flexplate won't spin at all. Some help please!
bcortell is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 07-13-2008, 07:19 PM   #3
Regular Member

shoebox's Avatar

Join Date: Aug 2006
Location: Little Rock, AR
Posts: 5,863
shoebox Tradesman Level Tech II
Default

Spark plugs out?
shoebox is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 07-13-2008, 07:35 PM   #4
CKJ
Guest

Posts: n/a
Default

How exactly are you trying? A flexplate turner or by the front crank bolt? Get a 1/2" breaker bar w/ a 5/8's socket and turn that mutha.

Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 07-13-2008, 09:21 PM   #5
Regular Member

Jpack's Avatar

Join Date: Sep 2005
Location: Sugar Grove, IL
Posts: 439
Jpack Apprentice Level Tech III
Default

Unless the blown motor = locked up motor.
__________________

Nifba.proboards.com

Clayton Racing 398, Rossler TH350 with brake, Dana S60, 250 shot, UMI Performance, Spohn, Baer brakes, 3000 race weight. Street driven race car.
Jpack is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 07-13-2008, 10:48 PM   #6
Regular Member

Join Date: Jul 2008
Posts: 7
polarisfan user's tech expertise is unknown at this point
Default

well if the motors blown it could be seized up
polarisfan is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 07-13-2008, 10:54 PM   #7
CKJ
Guest

Posts: n/a
Default

If the motor is indeed locked up, you'll have at least one way to get the motor to spin over.

Usually if the motor is locked due to bearings seizing then its usually the main bearings. Try dropping the oil pan and undoing the main caps 1 at a time and take out the top bearing. So at least the bottom of the crank journal is still in the bearing. That should get you turning the motor over. Unless its a rod that has siezed..which try to unbolt it and knock the bearing out.

Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 07-14-2008, 01:27 AM   #8
Regular Member

Join Date: Jul 2008
Location: Cleveland, OH
Posts: 12
bcortell user's tech expertise is unknown at this point
Default

Yes spark plugs are out.

I tried to turn the flexplate itself with a pair of gloves and two hands. Then i tried to turn it at the front of the engine.. no luck either way.

I'll drop the oil pan and all that when i have some free time in the next couple days. Thanks for the help.

(and i guess a pushrod blew-or came undone from a rocker- but i that's just what the guy said, so take it for what it's worth.)
bcortell is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 07-14-2008, 01:53 AM   #9
Regular Member

6spdphoenix's Avatar

Join Date: Jul 2008
Location: mi
Posts: 105
6spdphoenix user's tech expertise is unknown at this point
Send a message via AIM to 6spdphoenix Send a message via Yahoo to 6spdphoenix
Default

Are you looking to save the engine as a rebuild or just want it out of there? I would try a flywheel wrench or as said above,a breaker bar on the front of the crank. if it comes down to it,you could always pull a head and beat the top of the pistons untill the engine rolls over. That is of cousre if the engine is worth nothing more to you then a paper weight,other wise...dont do it lol. Good luck!
__________________
1995 Pontiac Firebird Formula 388 lt1 stroker with M-6 6speed......MODS.....CAI,Pace setter mid length headers,ORY pipe,Hooker super comp cat back,Cat delete,Holley 52mm throttle body,8.5mm wires,Delco platinums,B&M ripper short throw with hurst pistol grip handle,stage 2 clutch,17" bfgoodrich G force kdw tires,.060 over flat tops,stroked out to 388,blocks been decked down,stock spec cam,lifters,pushroads,rockers,heads,intake.a few other odds and ends
6spdphoenix is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 07-14-2008, 11:46 AM   #10
Regular Member

Greg Norris's Avatar

Join Date: Sep 2007
Location: Chuckteezy SC
Posts: 1,132
Greg Norris Apprentice Level Tech I
Default

what is wrong with the motor to begin with? you say its blown, but not why. could be a seized block, a dropped valve, seized bearings, or any number of other things. have you pulled the tranny all the way off?
__________________
From the past 10 years about 90% of Ford trucks are still on the road, the other 10% made it home.
Greg Norris is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 07-14-2008, 11:47 AM   #11
Regular Member

Greg Norris's Avatar

Join Date: Sep 2007
Location: Chuckteezy SC
Posts: 1,132
Greg Norris Apprentice Level Tech I
Default

motor blown.... probably seized... wont spin...
__________________
From the past 10 years about 90% of Ford trucks are still on the road, the other 10% made it home.
Greg Norris is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 07-14-2008, 02:49 PM   #12
Administrator

03slowZ06's Avatar

Join Date: Jul 2006
Location: Jacksonville
Posts: 7,520
03slowZ06 Apprentice Level Tech III
Send a message via Yahoo to 03slowZ06
Default

Is the tranny in neutral? If its an auto it does not matter. But I have seen alot of people call a flywheel a flex plate.
__________________
03 Z06, LTs, A&A P1SC running 6psi, 550/471
Quote:
Originally Posted by 94FormulaBird View Post
drivers side is a dream....passenger side on the other hand...i lost 2 screwdrivevers and a socket when i chucked them in the woods

u can do it



I am permanently banned from all petting zoo's for getting to friendly
03slowZ06 is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 07-14-2008, 06:12 PM   #13
Regular Member

Join Date: Jul 2008
Location: Cleveland, OH
Posts: 12
bcortell user's tech expertise is unknown at this point
Default

What does seized up mean exactly?

and it's an auto.. and in neutral..
bcortell is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 07-14-2008, 06:28 PM   #14
Administrator

03slowZ06's Avatar

Join Date: Jul 2006
Location: Jacksonville
Posts: 7,520
03slowZ06 Apprentice Level Tech III
Send a message via Yahoo to 03slowZ06
Default

Siezed up means that either the piston(s) are jammed up in the cylinders or the bearings are stuck to the crank. It is just a term used to describe the motor not being able to be turned.
__________________
03 Z06, LTs, A&A P1SC running 6psi, 550/471
Quote:
Originally Posted by 94FormulaBird View Post
drivers side is a dream....passenger side on the other hand...i lost 2 screwdrivevers and a socket when i chucked them in the woods

u can do it



I am permanently banned from all petting zoo's for getting to friendly
03slowZ06 is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 07-14-2008, 08:29 PM   #15
CKJ
Guest

Posts: n/a
Default

I think he really doesn't know why its blown. The previous owner said something but he's not sure. Hell before I put to much time/effort into a car that had something wrong with the motor i'd definatly pull it out and go through her.
